Suitable For Dry Mixing Of Products In Granule Form Easy For Loading And Unloading Of Material Easy For Cleaning.
All Contact Parts Are Made Out Of S.S 304/S.S 316 Or S.S 316 L Quality Material, As Per Customer Requirement.
The Octagonal Shape & Slow Speed Of Rotating Gives Sufficient Continuous Movement To The Granules, Result In Good Quality.
Simple Design Requires Minimum Maintenance. General Structure & Safety Guards Made Out Of Mild Steel & Coloured In Standard.
Model And Made Out Of S.S 304 &Polished To The Matt Finish In Gmp Model .
Maximum Care Has Been Taken To Ensure Safe Operation Of The Unit.
Manual Rotating Facility With Hand Wheel For Inching.
Bigger Size Batch At Low Power Consumption.
Depending On The Product.
Technical Details
| Capacity in kgs | Capacity in ltr | Gross Volume | Motor | Discharge valve | Overall Dimension
L X W X H |
| 50 | 100 | 110 | 2 | 2’’ | 700 X 600 X 1300 |
| 100 | 200 | 220 | 3 | 4’’ | 1200 X 900 X 1500 |
| 150 | 300 | 340 | 3 | 4’’ | 1300 X 1000 X 1700 |
| 200 | 400 | 450 | 5 | 5’’ | 1500 X 1400 X 1900 |
| 250 | 500 | 600 | 5 | 5’’ | 2300 X 1500 X 1900 |
| 300 | 600 | 650 | 7.5 | 6’’ | 2700 X 2100 X 3050 |
| 500 | 1000 | 1250 | 7.5 | 6’’ | 2850 X 2525 X 3120 |
