Multi Mill Machine

Multi Mill Machine

Avaibility: In Stock

Salient Features

Direction Of Beaters Can Be Changed By Reversible Switch From Knife To Impact Forward And Vice-Versa.

Cylindrical Screen For Higher Output. All Contact Parts Can Be Easily And Quickly Dismantled And Cleaned.

S.S. 316 Contact Parts Except Beaters And Scrapper Blades.

S.S.401 Beaters And Scrapper Blades (Hardened & Hard Chrome Plated). Castors With Breaks Provided For Easy Mobility. Depending On The Product.

Technical Details

Model VPT 1 HP VPT 2 HP VPT 3 HP VPT 5 HP VPT 7.5 HP
Output(kg/hr) 10 to 50 20 to 100 50 to 200 100 to 350 200 to 500
Rotor speed(rpm) 750/1500/2300/3000 750/1500/2300/3000 750/1500/2300/3000 750/1500/2300/3000 750/1500/2300/3000
Beaters 12 nos, with knife and impact edge & 2scraper blades. 12 nos, with knife and impact edge & 2scraper blades. 12 nos, with knife and impact edge & 2scraper blades. 12 nos, with knife and impact edge & 2scraper blades. 12 nos, with knife and impact edge & 2scraper blades.
Charging height (MM) 125 125 150 200 250
Discharging height (MM) 500 500 800 800 100
Electrical motor 1 hp, 3phase AC 2 hp, 3phase AC 3 hp, 3phase AC 5 hp, 3phase AC 7.5 hp, 3phase AC
